Miniature Solenoid Air Valve
This example of an ultra small solenoid air valve is suitable for a variety of low pressure applications.
This ultra-small solenoid air valve is suitable for a variety of low pressure applications. It is also ideal for applications with a tight space and/or weight constraints.
Typical Applications
Features and Benefits
- Low power consumption
- Compact design
- Can be configured as on-off or latching operation for battery operated applications
- Downloads
All TLX components are customized to fit system requirements, meaning technical specifications are unique to each customer and design. Examples given on our website are for illustration purposes only.
Is our Miniature Solenoid Air Valve the right fit for your application?
TLX Technologies partners with the world’s top brands, first-tier suppliers, and OEMs. Contact our engineers today to discuss the details of your project.
Automating Support in Running Shoes with Solenoids
A manufacturer of running shoes wanted their shoes to automatically adjust to the speed of the wearer, providing additional comfort and support. TLX designed a miniature solenoid air valve with magnetic latching technology to integrate into the shoe’s cushioning system.
Our engineers begin by designing with 3D CAD and performing electromagnetic and fluid dynamic analysis with state-of-the-art finite element analysis software. Every design is engineered and tested in our lab to meet our customers’ specifications.
Increased Performance
Precise control with high accuracy through tighter tolerances. Reducing friction and inefficiencies provides extremely low hysteresis.
Lighter Weight
Multiple variables in the design and manufacturing process are optimized to reduce overall weight and size of the solenoid or valve.
Minimized Footprint
Custom solenoids can be designed to utilize the best control scheme for your application, resulting in a minimized footprint.
Limited Power Consumption
Latching technology in solenoid and valve design minimizes overall power consumption.
Extreme Environments
Can be designed to meet extreme environments that include moisture, dirt/dust, vibration and/or extreme temperature requirements.
Built-in Safety
Failsafe modes are designed into solenoids and valves utilizing integrated electronic controls.
